InLine 76696C Datenblatt PDF herunterladen

Telefon: +49 (0)641 / 9726-0 · Telefax: +49 (0)641 / 9726-111

E-Mail: [email protected] · Internet: www.inline-info.de

« ZURÜCK

Category: I/O-Cards / Cardreader, PCIe

Inline® Interface card, SATA 6Gb/s controller card 2-channel, x1

PCIe 2.0, RAID 0/1/SPAN

Art.-Nr.:76696C - EAN:4043718220625

Based on the ASMedia ASM1061R PCI Express 2.0 SATA 6Gb/s controller, PCI Express x1 interface

allows communication speed of 2.5Gb/s and 5Gb/s.

Compliant with PCI Express Base 2.0 specification

Supports low-profile bracket

Supports Windows built-in drivers

SATA interface: 2x SATA 6Gb/s connector

Compliant with SATA Revision 3.2

Compliant with SATA AHCI specification Rev. 1.3

Supports data transfer 6Gb/s, 3Gb/s, 1.5Gb/s

For connecting SATA III, SATA II and SATA hard drives and SSD suitable

1 2

PCIe 2.0, RAID 0/1/SPAN 1

Inhaltsverzeichnis

Seite 1 - PCIe 2.0, RAID 0/1/SPAN

Telefon: +49 (0)641 / 9726-0 · Telefax: +49 (0)641 / 9726-111E-Mail: [email protected] · Internet: www.inline-info.de« ZURÜCKCategory: I/O-Cards

Seite 2

Supports NCQOptionally, the operation of RAID 0, RAID 1 or SPAN mode can usedSupports Automatic RebuildSystem Requirements: PC with one free PCI Expre
