USB 3.0 Express Card / 34mm (2-Ports),

InLine®

Art.-No.: 66742I

EAN: 4043718189977

The USB 3.0 ExpressCard is compliant to USB 3.0 standards and backward compatible

with USB 2.0 devices. It also allows you to connect multiple peripherals to your PC at the

same time. The USB 3.0 2-Port ExpressCard enhances the performance of transmission

that excessively faster than existing USB 2.0 devices. It is the ideal interface for transferring

extremely large amounts of data from USB 2.0/3.0 compliant products such real-time video

cameras, portable devices and others.

Compliant with Universal Serial Bus 3.0 specification Revision 1.0

Supports the following speed data rate as follows; Low-speed (1.5 Mbps) / Full-speed

(12 Mbps) / High-speed (480 Mbps) / Super-speed (5 Gbps)

Supports 2 downstream ports for all levels of speed

Supports all USB compliant data transfer type: Control / Bulk / Interrupt / Isochronous

transfer

Supports ExpressCard? Standard Release1.0

Supports Bus Power each port 100mA (Max.); Self power by external power adapter:

5V/2.5A (each port up to 900mA)

supports Windows XP / Vista / Windows 7
